CATIA V5 tutorials sketcher#3 important tools for sketcher,how hide and show tools.

so we are very near to start catia sketcher but we must know which tools importatnt to make sketch and how to put them on screen how to hide and show toolbars.
note these tool bars name -
1.Sketch tools
2-draw
3-operation
4-constraint
5-select
6-bottom tool bar
these tool must be have on your screen to drew circle,line,rectangle,edit and delete and mirror many more things.
for hide click on cross button at right top and if you want back that tool tab right click on right or top tool bar to get all list of tools choose any and click to get that tab.
